HAL3000 & AS20

BROCHURE DATA SHEET

Code : HAL3000-AS20

Description

HAL3000

The HAL3000 plaster saw utilises an oscillating movement for cutting. The amplitude of the oscillation is such that the blade is able to cut the stiff material but not the soft material that adapts to or follows the movement. This allows the layer of plaster to be easily cut while leaving the skin underneath unharmed.

AS20

The AS20 vacuum cleaner works in combination with the HAL3000 plaster saw. It is lodged inside a trolley that makes the entire system easy to transport and housing the saw and accessories used. AS20 automatically turns on when HAL3000 is turned on, and it automatically turns off a few seconds after the saw is turned off.

Engineering data

HAL3000

Electric power supply: 230 V AC 50/60 Hz
Power: 250 W
Oscillations: 15,000/min.
Weight: 1.4 kg
Blades: circular Ø65 and Ø50 square coupling
Electrical safety: Class 2 B according to the EN 60601-1 Standard
Electromagnetic compatibility: Group 1 Class B EN 60601-1-2 Standard
Classification according to EEC 93/42 Directive: Class I
NOTE: HAL3000 powered with 110V can be supplied on request.

AS20

Electric power supply: 230 V AC 50/60 Hz
Power: 1000 W
Electrical safety: Class 1 B according to the EN 60601-1 Standard
Electromagnetic compatibility: Group 1 Class B EN 60601-1-2 Standard
Classification according to EU 93/42 Directive: Class I
NOTE: AS20 powered with 110V can be supplied on request.

Consumables & spare parts

HAL3000

Blades Medium Hard • Ø 50mm / 65mm • 10 pcs. / 50 pcs

Blades Extra Hard • Ø 50mm / 65mm • 10 pcs

AS20

Plastic filter

Filter (unit)

Spare bags
